1080P High Sensitivity Accuracy 0.3 120db WDR Body Temperature Measurement Camera AI Intelligence Camera Bi-spectrum Network Cam

Since launched,IP Camera/NVR/Solar Camera/Smart Battery Camera has been named as one of the best and popular products in our company. Manufactured following the strict management system, our 1080P High Sensitivity Accuracy 0.3 120db WDR Body Temperature Measurement Camera AI Intelligence Camera Bi-spectrum Network Cam has gained a reliable quality. Before its launch, it has passed the tests based on international rules and is certified by several authorities. LSVISION is worth the investment for those customers seeking business opportunities. With a comprehensive understanding of the company management system, our employees can better realize their duties, which contributes to higher-efficiency manufacturing and more professional services. Our goal is to be a leading company in the global market.

1080P High Sensitivity Accuracy 0.3 120db WDR Body Temperature Measurement Camera AI Intelligence Camera Bi-spectrum Network Cam

Descrição do produto

Modelo	LS-TI004
Thermal Camera
Tipo de sensor	Uncooled IRFPA Microbolometer
Resolução	400(H) ×300(V)
Pixel Interval	17um
Thermal Sensitivity (NETD)	≤40mK @F1.0, 300K
Spectral Range	8~14um
Image Setting	Polarity LUT/ DVE/ Mirror/ FCC/ /3D DNR Brightness/Contrast/ ROI
Color Palettes	Black-Heat /White-Heat/Rainbow/Iron-Red up to 17 modes
Thermal lens
Lens Type	Fixo
Focus Control	Manual Focus
Focal Length	8mm
F No.	F1.0
Angle of View	H: 46°, V: 35°
Visible Camera
Sensor de imagem	1/2.8″ Sony CMOS
Effective Resolution	1920(H)×1080(V)
Shutter Speed	1/5 ~ 1/20,000s
Wide Dynamic Range	True WDR 120dB
Min. Iluminação	Color: 0.1Lux @(F1.2, AGC ON) B/W: 0.01Lux @(F1.2, AGC ON)
S/N Ratio	More than 55dB
Focal Length	2.7 ~ 12mm
Max Aperture	F1.6~ F2.9
Angle of View	105°~ 32°
Focus Control	Motorized
Video and Audio
Compression	H.265, H.264, MJPEG
Taxa de quadros	Main Stream: Visible: 1920×1080/1280×720 @25/30fps Thermal: D1 @25/30fps Sub Stream: Visible: D1/VGA/640×360/CIF/QVGA @25/30fps Thermal: CIF @25/30fps
Bit Rate Control	CBR/VBR
Bit Rate	Main Stream: Thermal: 100Kbps~6Mbps Visible: 100Kbps~12Mbps Sub Stream: Thermal: 10Kbps~1.5Mbps Visible: 10Kbps~6Mbps
Region of Interest	Off / On (8 Zone, Rectangle)
Digital Zoom	16x
Mirror	Apoio
Desembaciamento	Apoio
Deteção de movimento	Apoio
Privacy Masking	Off / On (4 Area, Rectangle)
DVE Image Enhance	Apoio
Compressão de áudio	G.711, RAW_PCM
Intelligence
Intelligent Functions	Motion detection, Disk alarm, I/O alarm, Temperature alarm
IVS	Smart Body Detection, Perimeter ,Single Virtual Fences ,Double Virtual Fences ,Object Left ,Object Removed
Temperature Detection
Detection Mode	Body temperature monitoring
Detection Preset	Max 30 goals
Temperature Alarm	Over temperature alarm
Accuracy	± 0.3 ℃ (Emission rate, distance, ambient temperature, etc.) with blackbody Detection Distance: 3~5m (4m recommended)、Working Environment: Avoid the interference of wind, sunshine, high temperature and reflective objects, indoor is recommended
Response Time	≤30ms
Theory of temperature measurement range	-20 °C ~ 60 °C (-4°F ~ 140°F)
Rede
Ethernet	RJ-45 (10/100Base-T)
Protocolos	IPv4/IPv6 ,HTTP,RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, PPPOE, SMTP, SIP ,802.1x
Interoperability	ONVIF, CGI, SDK
Streaming Method	Unicast
Max. User Access	10 Users
Armazenamento de borda	Local PC for instant recording Micro SD card 128GB
Web Viewer	<IE11, Chrome, Firefox
Web Language	English, Chinese, Polish, Italian, Portuguese, Spanish. Russian, French, Czech, Hungarian
Interface
Ethernet	1 Ethernet (10/100 Base-T) RJ-45 Connector
Audio Interface	1ch Audio In,1ch Audio Out
Alarme	2ch Alarm In,2ch Alarm Out
RS485	Apoio
BNC Output	N/A
Reset Button	Support (Built-in)
Geral
Fonte de alimentação	DC12V/POE (IEEE 802.3af)
Consumo de energia	Max 10W
Operating Temperature	-30°C~60°C(-22°F~140°F)
Storage Conditions	0~ 90% RH
Certificações	CE /FCC
Ingress Protection	IP66
Casing	Metal
Dimensões	212×182×136mm
Net Weight	2.1Kg
