Utilizing technology makes the manufacturing process go smoothly and efficiently.With regard to the product advantages, the product can be widely found in the field(s) of binocular thermal camera manufacturer factory CE FCC Certification strict quality control thermal imaging camera. Based on binocular thermal camera manufacturer factory CE FCC Certification strict quality control thermal imaging camera properties, we have selected technology to manufacture the product after conducting multiple tests and experiments.Our product is qualified for being used in the application field(s) of Thermal Camera & Face recognition. For product inquiries, technical support, and other questions, you can reach us in any way stated on our ‘Contact Us’ page.
| Место происхождения: | Гуандун, Китай | Название бренда: | ВИДЕНИЕ ЛС |
| Номер модели: | LS-TI003 | Специальные возможности: | Водонепроницаемый / погодоустойчивый |
| Сенсор: | CMOS | Формат сжатия видео: | H.264 |
| Варианты хранения данных: | PC | Название продукта: | thermal imaging camera |
| Особенность: | binocular | Функция: | Fever Detection with Alarm Function |
| Разрешение: | 1920*1080 | Thermal Image Pixel: | 256*192 |
| Temperature Detection Accuracy: | ±0.3℃ | Support: | simultaneous detection of 20-30 faces |
| Web Client Language: | English, Chinese | Work Temperature: | -20°C to 55°C |
| Применение: | train stations, subway stations, shopping malls, hospital, school | Сертификация: | CE , FCC |
Название здесь.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
|
Mode
|
LS-TI003
|
|
Thermal
|
|
|
Датчик изображения
|
Vox Uncooled Focal Plane Arrays
|
|
Разрешение
|
256×192
|
|
Pixel Interval
|
12pm
|
|
NETD
|
Less than 60 mK (@25°C.F#=1.1)
|
|
Апертура
|
F1.0
|
|
Field of View
|
35° x 27° (H x V)
|
|
Optical
|
|
|
Датчик изображения
|
1/2.8″ 2.0M Pixel CMOS
|
|
Разрешение
|
1920x1080P
|
|
Мин. Освещение
|
Color: 0.005Lux @ (F1.2, AGC ON), B/W 0.001 皿@ (F1.2, AGC ON)
|
|
Field of View
|
84° x 45° (H x V)
|
|
Focal Length
|
4mm
|
|
Shutter Speed
|
1s to 1/100,000s
|
|
Баланс белого
|
Auto/Manual/ATW (Auto-tracking White Balance)/lndoor/Outdoor/Daylight Lamp/Sodium Lamp
|
|
День и ночь
|
ModeiR cut filter with auto switch
|
|
WDR
|
80 dB
|
|
Характеристика
|
|
|
Bi-spectrum Image Fusion
|
Fusion view of thermal view and overlaid details of the optical channel
|
|
Picture in Picture
|
Combines details of thermal and optical image PIP, overlay thermal image on optical image
|
|
Smart Function
|
|
|
Face snapping
|
Built-in deep learning Al algorithm, Supports simultaneous detection of
|
|
20-30 faces
|
|
|
Temperature Measurement
|
Support global and local temperature
|
|
Temperature Range
|
From-15°C to +150°C
|
|
Temperature Accuracy
|
Target temperature 35°C A 38°C ±0.3 °C
|
|
Target temperature 20°C A 33°C ±0.6 °C
|
|
|
Target temperature 38°C A 50°C ±0.6 °C
|
|
|
Сеть
|
|
|
Основной поток
|
Thermal: 25fps(1920 x 1080, 1280 x 720)
|
|
Sub Stream
|
Thermal: 25fps(704 x 576, 352 x 288)
|
|
Сжатие видео
|
H.264 (Baseline/Main/High Profile) /MJPEG/H.265
|
|
Сжатие звука
|
G 711u/G711a/G.7221/MP2L2/G.726/PCM
|
|
Протоколы
|
TCP/IP, , GB/T 28181, DHCP. RTP, RTSP,PPPoE UPnP, UDP
|
|
API
|
(Profile S, Profile G, Profile T), SDK
|
|
Общие сведения
|
|
|
Web Client Language
|
languages English, Chinese
|
|
Мощность
|
DC 12V, 0.65A
|
|
Work Temperature/H umidity
|
From -20°C to 55°C; Humidity: 95% or Less
|
|
Protection Level
|
IP66
|
|
Размер
|
246 mm x 101 mm x 81 mm (with bracket)
|
|
Вес
|
Approx. 1.0 kg
|
