Shenzhen LSVISION Technology Co., Ltd. has been focusing on improving technologies to develop new products on a regular basis. We have successfully made 2.8 Inch TFT Screen Handheld Body Screening Smart Alarm Buzzer Thermal Imager Measurement Heat Camera Range 30C~45C In Stock launch to the public as scheduled. With its new features, IP Camera/NVR/Solar Camera/Smart Battery Camera is expected to lead the industry trend. High-end technologies are adopted to manufacture the product.When the product is manufactured and used in the field(s) of CCTV Camera, its stability and advantages can be fully played out. The specifications of 2.8 Inch TFT Screen Handheld Body Screening Smart Alarm Buzzer Thermal Imager Measurement Heat Camera Range 30C~45C In Stock can be customized according to your needs.
| Место происхождения: | Гуандун, Китай | Название бренда: | LSVISION |
| Номер модели: | LS-TI001K | Специальные возможности: | Waterproof / Weatherproof, Waterproof / Weatherproof |
| Сенсор: | CCD, CCD | Формат сжатия видео: | H.265 |
| Название продукта: | Handheld Body Screening Smart Alarm Buzzer Thermal Imager | Разрешение: | 19200 (160*120) |
| Accuracy: | ±0.5℃ | Temperature range: | 30℃~45℃ |
| Источник питания: | DC 12V, 0.65A | Датчик изображения: | Uncooled focal plane array |
| Frame rate: | <9Hz | Display resolution: | 320*240 |
2.8 Inch TFT Screen Handheld Body Screening Smart Alarm Buzzer Thermal Imager Measurement Heat Camera Range 30C~45C In Stock
|
Модель
|
LS-TI001K
|
|
|
Thermal Camera
|
||
|
Тип датчика
|
Uncooled focal plane array
|
|
|
Temperature range
|
30℃~45℃
|
|
|
Разрешение
|
0.1℃
|
|
|
Accuracy
|
±0.5℃（ @ 25℃ ambient temperature）
|
|
|
Minimum measuring distance
|
15cm
|
|
|
Optimal measuring distance
|
1m
|
|
|
Temperature measurement response time
|
≤500ms (95% of reading)
|
|
|
Thermal resolution
|
19200 (160×120)
|
|
|
Датчик изображения
|
12μm
|
|
|
Palettes
|
Iron red, rainbow, glowing white, glowing black, glowing red, lava, high-contrast rainbow
|
|
|
Bandwidth of infrared spectroscopy
|
8~14μm
|
|
|
Field of view (FOV)
|
56°(H) × 42°(V)
|
|
|
Instantaneous field of view (IFOV)
|
6mrad
|
|
|
Thermal imaging sensitivity
|
＜50mk
|
|
|
Частота кадров
|
＜9Hz
|
|
|
Temperature display
|
Center temperature measurement and high temperature tracking (default)
|
|
|
Формат изображения
|
BMP
|
|
|
Image mode
|
Thermal camera, visible camera, image blending
|
|
|
Temperature measuring point
|
Besides central point, 3 temperature measuring points can be added
|
|
|
Display resolution
|
320×240
|
|
|
Visual camera
|
||
|
Resolution of visible camera
|
640×480
|
|
|
Display resolution
|
320×240
|
|
|
Image blending
|
0% (total visual camera), 25%, 50%, 75%, 100% (total thermal camera)
|
|
|
PC analysis software (PC)
|
||
|
Real-time image transmission
|
Н/Д
|
|
|
PC analysis software（PC）
|
Н/Д
|
|
|
Data communication
|
Н/Д
|
|
|
Auto power off
|
Selectable (5min, 10min, 30min), 30min auto power off (default)
|
|
|
Battery life
|
≥6 hours |
|
|
Время зарядки
|
5 hours
|
|
|
Charging voltage/current
|
5V/2A
|
|
|
Image storage
|
Micro SD card
|
|
|
Мощность
|
A single Li-ion 3.7V/5000mAh 26650 battery |
|
|
Display
|
2.8″ TFT LCD |
|
|
Product color
|
Red + grey
|
|
|
Product size
|
236mm x 75.5mm x 86mm
|
|
|
Standard accessories
|
Manual, 16GB TF card
|
|
|
Standard carton gross weight
|
2.2kg
|
|
