It is AI tuya nvr 4ch 8ch cctv home security p2p 1080P 2MP 4 8 channel wifi wireless nvr camera system kit features and appearance that differentiates it from other products in the market. We pay close attention to the selection of raw materials and the use of manufacturing technologies. In this way, the quality and performance of IP Camera/NVR/Solar Camera/Smart Battery Camera can be better guaranteed. At Shenzhen LSVISION Technology Co., Ltd., it is our goal to provide the highest quality products and superior service to our customers, both being our top priority. Relying on our excellent products and sensible marketing strategy,Shenzhen LSVISION Technology Co., Ltd. hold a firm belief that we will take a large market share in the future and benefit our stakeholders as well.
| Місце походження: | Гуандун, Китай | Назва бренду: | LSVISION |
| Номер моделі: | LS-WK4214 | Ключова особливість 1: | Plug and Play, remote control |
| Ключова особливість 2: | Waterproof, support APP, CMS and IE Browser View | Main processor: | Hi3536D |
| Warranty: | 2 Years Warranty kit video surveillance wireless | ЖОРСТКИЙ ДИСК: | support 1 SATA max 6T |
| Lens: | 3.6mm Fixed lens | Wifi Signal: | 100-150M |
| Нічне бачення: | 20 Meters IR Distance for Night Vision | Accessories: | With 1 meter reticle*1 ;Power adaptor*9;Mouse*1 |
| Certificate: | CE ROHS FCC |
|
Модель
|
LS-WK4214
|
|||
|
NVR Specification
|
||||
|
Система |
Main processor
|
Hi3536D
|
||
|
Операційна система
|
Вбудований Linux
|
|||
|
Відео
|
Video compression
|
H.265 High Profile/ H.264 Main Profile
|
||
|
Відеовихід
|
720P60,XGA,1080P60
|
|||
|
Video input(IP)
|
8*1080P/8*960P/8*720P
|
|||
|
Аудіо
|
Audio compression
|
G.711
|
||
|
intercom
|
None
|
|||
|
Record & playback
|
Recording mode
|
Manual/Alarm/Video Detection/Continuous
|
||
|
Local Playback
|
1*1080P
|
|||
|
Storage & Backup
|
Record Storage
|
network
|
||
|
Backup mode
|
Network backup, USB hard disk
|
|||
|
Управління мережею
|
Протокол
|
TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,ONVIF,SADP,P2P
|
||
|
Wireless
|
Frequency
|
2.4G
|
||
|
Antenna Structure
|
2 × 2MIMO
|
|||
|
Distance
|
More than 200 meters with no obstacle，more than 40 meters if penetrate the wall， the actual transmission distance according to the
situation |
|||
|
Інтерфейс
|
Відеовихід
|
1ch VGA output
|
||
|
Audio I/O
|
None
|
|||
|
Alarm I/O
|
None
|
|||
|
Network interface
|
1*RJ45 10M/100M Adaptive Ethernet port
|
|||
|
USB
|
2*USB 2.0 port
|
|||
|
Hard disk
|
1 SATA(Up to 4TB)
|
|||
|
Oter
|
Power supply
|
DC +12V /3A
|
||
|
Power Consumption
|
5W（Without HDD）
|
|||
|
Work environment
|
Temperature:-10℃－＋55℃, Humidity:10%-90%RH
|
|||
|
Технічні характеристики IP-камери
|
||||
|
Модель
|
/
|
|||
|
2.0Mp Wireless IP Camera
|
||||
|
Image sensor
|
1/2.9″ 2.0M Pixel CMOS
|
|||
|
Об'єктив
|
3.6 mm
|
|||
|
Lens Mount
|
M12
|
|||
|
Min. Illumination
|
Color：0.01Lux@(F1.2，AGC ON) B/W：0.001Lux@(F1.2，AGC ON）,0Lux @（IRled ON)
|
|||
|
S / N ratio
|
≥39dB
|
|||
|
Shutter speed
|
1/5 – 1/20,000s，
|
|||
|
Day & Night
|
Day / Night / External control（IR Cut Filter）
|
|||
|
AGC
|
Auto / Manual
|
|||
|
White balance
|
Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
|
|||
|
Wide dynamic range
|
Digtal Wide dynamic range
|
|||
|
Digital noise Reduction
|
2DNR,3DNR
|
|||
|
Стиснення відео
|
H.265 Main Profile/H.264 Main Profile/M-JPEG
|
|||
|
Стиснення звуку
|
G711，PCM
|
|||
|
Max.Image Resolution
|
1920×1080@20fps
|
|||
|
Image Resolution
|
Main stream （1920×1080、1280×960、1280×720、720×576、640×480）
|
|||
|
sub-stream （640×480、352×288、320×240、176×144）
|
||||
|
Bitrate
|
CBR/VBR, bitrate：32Kbps~10Mbps variable
|
|||
|
Motion detect
|
Підтримка
|
|||
|
AI
|
Human detection
|
|||
|
Privacy Zone Masking
|
4 privacy masks programmable
|
|||
|
P2P
|
Android、IOS
|
|||
|
Protocols
|
TCP/IP，HTTP， NTP，IGMP， DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS， P2P
|
|||
|
Onvif
|
Non- Support
|
|||
|
Wireless
|
Frequency:2.4G
|
|||
|
Transmission distance :More than 200 meters with no obstacle， More than 30 meters if penetrate the wall， The actual transmission
distance according to the situation |
||||
|
Power
|
12VDC
|
|||
|
Розміри
|
38x38x5mm
|
|||
|
Робоча температура
|
-30°C ~60°C, Humidity≤90%RH(Unsupport-condensing)
|
|||
Quality Life”. The corporate value of “Quality, Innovation and Dedication”. We focus on the full hd security products and smart
home R&D, production and sales. Combined with the team wisdom is committed to creating the ultimate the high quality products and
services, to provide customers with intimate service and program system, we have won the title of “National High Tech
Enterprises”, “Shenzhen High Tech Enterprises” and “the Honesty Contract Enterprises”. combined with Monitoring Hardware and
Software committed to the smart security and smart home industry. Main Product Line is (2mp, 4mp 5mp and 4K) H.265 IP Camera,
H.265 HD NVR, Wireless NVR System, POE CCTV Kits, Hybrid CCTV Camera and DVR, 4G WIFI Solar CCTV Camera and Smart Home Series
System, all products have passed CE, RoHS, FCC and ISO90001 Quality Management System Certificate. At present, we have set
exclusive agency in more than 10 countries and regions, such as France, Italy, Chile, Canada, Serbia, Tunisia, Madagascar, Saudi
Arabia, Kuwait, Vietnam, Yemen, Bangladesh and other countries, products and services have been highly praised by customers. Our
products and solutions are widely used in a number of areas, including banking, public security, government justice,
transportation, education, Medical, health care and home security. It has played an important role in several large-scale security
projects around the world. such as airports, plazas, railway stations, exhibitions, gas stations and other public safety areas.
Shenzhen ls vision Technology Co., Ltd.
We have awarded the title of “China High-Tech Enterprises”.
Combined with Monitoring Hardware and Software Equipment,
for the Global User to Provide Security, Smart Home Solution and Services.
The company is committed to the Smart Security and Smart Home Industry.
LS VISION Core Value: “Quality, Innovation, Dedication”.
LS VISION Mission: “Creating a Safer&Green World”.
LS VISION Technology Co., Ltd. is a full HD Video Surveillance Solutions Provider. We have won the title of “China High Tech Enterprises”, ”Shenzhen High Tech Enterprises” and ”Member Unit of Shenzhen Smart Security Chamber of Commerce”.
|
Main Markets
|
Total Revenue(%)
|
|
Eastern Europe
|
20.00%
|
|
South America
|
10.00%
|
|
Western Europe
|
10.00%
|
|
Central America
|
10.00%
|
|
Northern Europe
|
10.00%
|
|
Southern Europe
|
10.00%
|
|
North America
|
5.00%
|
|
Southeast Asia
|
5.00%
|
|
Африка
|
5.00%
|
|
Океанія
|
5.00%
|
|
Східна Азія
|
3.00%
|
|
Внутрішній ринок
|
3.00%
|
|
Близький Схід
|
2.00%
|
|
Південна Азія
|
2.00%
|
Завжди передсерійний зразок перед масовим виробництвом;
Завжди остаточна перевірка перед відвантаженням;
3. що ви можете купити у нас?
IP-камера, комплект відеореєстраторів, бездротова домашня камера, камера з сонячною батареєю / PTZ, камера для вимірювання температури з розпізнаванням обличчя зі штучним інтелектом
4. чому варто купувати у нас, а не в інших постачальників?
LSVISION, китайські високотехнологічні підприємства. 15-річний досвід досліджень та розробок у сфері безпеки, постачальник систем відеоспостереження та розумного дому
Рішення. підтримка OEM та ODM. вся продукція пройшла CE, RoHS, FCC та ISO9001. більше 10 глобальних ексклюзивних агентств.
5. які послуги ми можемо надати?
Прийняті умови доставки: FOB, CIF, EXW；; FOB, CIF, EXW
Прийнята валюта платежу: USD, EUR, CNY;
Прийнятий тип оплати: T / T, кредитна картка, PayPal, Western Union, готівка;
Мова спілкування: англійська, китайська
