| Key Feature |
* 1/2.5″ CMOS sensor(SONY IMX274)
* Full HD resolution 8MP（3840 x 2160）
* Ultra low illumination 0.01Lux@F1.2
* Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
* D-WDR, Motion Detection, Privacy Mask, Mirror, rotate
* RTSP and 2.6 compatible
* /H.264 dual-stream media server
* Multiply web browser, PC Client
* Optional function（Audio,TF Card Slot)
* Lightning protection 4000V
* Strong water-proof housing, IP66
* 4 pcs new SMD IR Leds, IR distance 15 meters
* 4mm Fixed lens
* Support POE 48V
| Detail Image |
Specification |
|
Модель |
LS-NHB1801 |
|
Camera |
|
|
Датчик зображення |
1/2.5″ CMOS sensor(SONY IMX274) |
|
Effective Pixels |
3840*2160 |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
Color 0.01Lux/F1.2；black and white 0.001Lux/F1.2 |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
Баланс білого |
Авто |
|
AGC/BLC |
Підтримка |
|
DNR |
2D/3D DNR |
|
Інше |
Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Rotate |
|
Encode |
|
|
Embedded Solution |
Embedded RTOS, DSP(Novatek 96683) |
|
Video Standard |
Main Profile/MJPEG/ H.264HighProfile/ Main Profile/ BaseLine Profile |
|
Відео Резолюція |
Main stream: 3840*2160@25fps/1080P/720P@25fps Sub stream: VGA/360P@30fps, etc. |
|
Відео Bitrates |
160Kbps~20MKbps, VBR/CBR |
|
Audio Standard |
G.711A/G.711Mu |
|
IR Led |
|
|
IR Led |
4 pcs IR Leds |
|
IR Distance |
15M |
|
Об'єктив |
|
|
Focal length |
4mm Fixed lens |
|
Optional Function |
|
|
Audio, etc. |
|
|
Network Services |
|
|
Протокол |
TCP/IP；UDP；HTTP；IGMP ；ICMP；DHCP；RTP/RTSP；DNS；DDNS；FTP；NTP；PPPOE；UPNP；SMTP；SNMP |
|
P2P |
N/A |
|
Web |
IE |
|
Media |
CMS, IE |
|
|
2.6 compatible |
|
Генерал |
|
|
Network Port |
1-RJ45, 100Mbps, POE |
|
Джерело живлення |
Support POE 48V 12 VDC ± 10% |
|
Power Consumption |
< 7 W |
|
Operating Temp. |
–30℃-(+60)℃, 10%-90%RH |
*This statement is subject to change without notice
Certification |
LS VISION Brand and Security Project |
Глобальний бренд LS VISION
At present, LS VISION partners and customers all over the world, including dealers, agents, engineers and security importers, end consumers and other different customer groups, in Russia, Yemen, Philippines, Madagascar, Nigeria, Tunisia, Bangladesh, Saudi Arabia, Vietnam, Ghana, Bangladesh and other countries region, set up an exclusive agency, and we have been have been making great efforts to expend our global agency or distribution area.
Продукти та рішення LS VISION, використані в ряді країн і регіонів, таких як проект Міжнародного книжкового ярмарку в Джидді в Саудівській Аравії в 2017 і 2018 роках; проект відеоспостереження CITY Center MAKKAH в 2018 році; проект автозаправної станції Fath в 2017 році, перуанський проект Bass Amas Plaza, аеропорт в Панамі та інші великі проекти в області безпеки, зіграли важливу роль.
About LS VISION
|
Our R&D team engineers have more than 15 years experience for security products.
LS VISION Core Value: ” Quality, Innovation, Dedication“.
LS VISION Mission: “Only for Quality Life“.
Key Products Line:
HD IP Cameras, HD NVR, WiFi NVR Kit;
Analog HD Series: 4 in 1 Hybrid Camera, 5 in 1 Hybrid DVR;
Multi-sensor Panoramic Camera for Wide Angle Environment survelliance.
Натільна камера for Government & Police dept which support 4G function.
