Our professional engineers have expertise in using technologies. It has a wide scope of range and is widely seen in the field(s) of CCTV Camera. 4 Channel 1080P Tuya Home CCTV Wifi NVR Kit Waterproof Outdoor Surveillance Security IP Camera System With APP&Email Alarm Push provides not only excellent quality, but also very favorable price. Since our inception, Shenzhen LSVISION Technology Co., Ltd. have been striving forward with the aim of being a leading company in the globe. We will focus more on improving our R&D capabilities and upgrading technologies in order to develop more creative products, therefore leading the industry trends and keeping us competitive in the market.
| Lugar de origen: | Guangdong, China | Marca: | VISIÓN LS |
| Número de modelo: | LS-WK4214 | Garantía: | 1 año |
| Características especiales: | NIGHT VISION, Two-way Audio, Waterproof / Weatherproof | Sensor: | CMOS |
| Estilo: | BULLET CAMERA | Función: | Waterproof / Weatherproof, Two-way Audio |
| Formato de compresión de vídeo: | H.265 | Opciones de almacenamiento de datos: | NVR |
| Aplicación: | Interior, Exterior | Asistencia personalizada: | Asistencia técnica en línea, logotipo personalizado, OEM, ODM, reingeniería de software |
| Name: | 4CH Wireless Tuya 1080P HD-NVR Kit | Image sensor: | 1/2.9″ 2.0M Pixel CMOS |
| Resolución: | 1920*1080P | Hard disk: | 1 SATA(Up to 4TB) |
| Main processor: | Hi3536D | Operating System: | Linux integrado |
| Impermeable: | IP66 | Poder: | 12VDC |
| Canales: | 4 |
Detailed Image
Descripción del producto
* Automatic Wireless Connection, plug and play * 1080P H.265+ wireless network recorder and 4 1080P wireless cameras * In open space without itrefere transmission distance up to 200 meters *Insert professional surveillance Wireless board, with stonger anti-interfere ability * One-push to configure * Support alarm push motion detection and alarm output(voice/email/ FTP etc.) * AI Human detection * Support Android/Apple cell phone or pad by LAN & WAN visit and control * Support Tuya APP, fluent and fast remote access * Suit to homes, offices, small businesses & retail stores * Easy to Install, User-Friendly Operation
|
Modelo
|
LS-WK4214
|
LS-WK4204 4CH Wireless 1080P HD-NVR
|
||
|
NVR Specification
|
||||
|
Sistema
|
Main processor
|
Hi3536D
|
||
|
Lente
|
Sistema operativo
|
Linux integrado
|
||
|
Vídeo
|
Video compression
|
H.265 High Profile/ H.264 Main Profile
|
||
|
Wifi Signal
|
Salida de vídeo
|
720P60,XGA,1080P60
|
||
|
Day&Night
|
Video input(IP)
|
4*1080P/4*960P/4*720P
|
||
|
Audio
|
Compresión de audio
|
G.711
|
||
|
Stream
|
intercom
|
Ninguno
|
||
|
Record & playback
|
Recording mode
|
Manual/Alarm/Video Detection/Continuous
|
||
|
HDD
|
Local Playback
|
1*1080P
|
||
|
Storage & Backup
|
Record Storage
|
network
|
||
|
Mobile app
|
Backup mode
|
Network backup, USB hard disk
|
||
|
Control de red
|
Protocolo
|
TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,,SADP,P2P
|
||
|
Inalámbrico
|
Frequency
|
2.4G
|
||
|
Antenna Structure
|
2 × 2MIMO
|
|||
|
Distance
|
More than 200 meters with no obstacle,more than 40 meters if penetrate the wall, the actual transmission distance according to the
situation |
|||
|
Interfaz
|
Salida de vídeo
|
1ch , 1ch VGA output
|
||
|
Audio I/O
|
Ninguno
|
|||
|
Alarm I/O
|
Ninguno
|
|||
|
Network interface
|
1*Puerto Ethernet adaptable RJ45 10M/100M
|
|||
|
USB
|
2*USB 2.0 port
|
|||
|
Hard disk
|
1 SATA(Up to 4TB)
|
|||
|
Oter
|
Power supply
|
DC +12V /3A
|
||
|
Consumo de energía
|
5W(Without HDD)
|
|||
|
Entorno de trabajo
|
Temperature:-10℃-+55℃, Humidity:10%-90%RH
|
|||
|
IP Camera Specification
|
||||
|
Modelo
|
/
|
|||
|
2.0Mp Wireless IP Camera
|
||||
|
Image sensor
|
1/2.9″ 2.0M Pixel CMOS
|
|||
|
Lente
|
3.6 mm
|
|||
|
Lens Mount
|
M12
|
|||
|
Min. Iluminación
|
Color:0.01Lux@(F1.2,AGC ON) B/W:0.001Lux@(F1.2,AGC ON),0Lux @(IRled ON)
|
|||
|
S / N ratio
|
≥39dB
|
|||
|
Velocidad de obturación
|
1/5 – 1/20,000s,
|
|||
|
Day & Night
|
Day / Night / External control(IR Cut Filter)
|
|||
|
AGC
|
Auto / Manual
|
|||
|
White balance
|
Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
|
|||
|
Wide dynamic range
|
Digtal Wide dynamic range
|
|||
|
Digital noise Reduction
|
2DNR,3DNR
|
|||
|
Compresión de vídeo
|
H.265 Main Profile/H.264 Main Profile/M-JPEG
|
|||
|
Compresión de audio
|
G711,PCM
|
|||
|
Max.Image Resolution
|
1920×1080@20fps
|
|||
|
Image Resolution
|
Main stream (1920×1080,1280×960,1280×720,720×576,640×480)
|
|||
|
sub-stream (640×480,352×288,320×240,176×144)
|
||||
|
Bitrate
|
CBR/VBR, bitrate:32Kbps~10Mbps variable
|
|||
|
Motion detect
|
Ayuda
|
|||
|
AI
|
Human detection
|
|||
|
Privacy Zone Masking
|
4 privacy masks programmable
|
|||
|
P2P
|
Android,IOS
|
|||
|
Protocolos
|
TCP/IP,HTTP, NTP,IGMP, DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS, P2P
|
|||
|
Non- Support
|
||||
|
Inalámbrico
|
Frequency:2.4G
|
|||
|
Inalámbrico
|
Transmission distance :More than 200 meters with no obstacle, More than 30 meters if penetrate the wall, The actual transmission
distance according to the situation |
|||
|
Potencia
|
12VDC
|
|||
|
Dimensiones
|
38x38x5mm
|
|||
|
Temperatura de trabajo
|
-30°C ~60°C, Humidity≤90%RH(Unsupport-condensing)
|
|||
Comentarios de los clientes
Certificación
Marca y proyecto CCTV
LS VISION Marca global
En la actualidad, los socios y clientes de LS VISION en todo el mundo, incluidos distribuidores, agentes, ingenieros e importadores de seguridad, consumidores finales y otros grupos de clientes diferentes, en Rusia, Yemen, Filipinas, Madagascar, Nigeria, Túnez, Bangladesh, Arabia Saudí, Vietnam, Ghana, Bangladesh y otros países de la región, establecieron una agencia exclusiva, y hemos estado haciendo grandes esfuerzos para ampliar nuestra agencia global o área de distribución.
Proyecto de seguridad global LS VISION
Los productos y soluciones de LS VISION utilizados en varios países y regiones, Tales como el proyecto de la Feria Internacional del Libro de Jeddah de Arabia Saudita en 2017 y 2018; el proyecto de CCTV del CITY Center MAKKAH en 2018; el proyecto de la gasolinera Fath en 2017, el proyecto peruano Bass Amas Plaza, el aeropuerto de Panamá y otros grandes proyectos de seguridad han desempeñado un papel importante.
VISIÓN LS
LS VISION mantendrá nuestro valor clave de Calidad. Innovación. Dedicación investigar más los productos para aportar más valor a nuestros socios en 2019.
En 2019, estrategia de productos LS VISION:
Mercado industrial:
IPC: Serie 4K de 2MP a 8MP Cámara IP y NVR HD sistema.
Alta definición analógica: series de 2MP a 8MP y sistema DVR.
Serie AI: Cámara de reconocimiento facial y el sistema NVR.
Sistema de cámara solar 4G
Mercado de consumo:
Kit NVR Wifi, Kit Nvr POE;
wifi Batería Cámaras, Cámara PTZ wifi, Timbre inteligente etc.
