| Fő jellemző |
24.0MP 8-Sensors Panoramic Dome IP Camera
360°panoramic sight based on 8-sensor connection
High-efficiency economic installation，industrial high-quality optical lens
Support ePTZ to look multiple regions
8×3.0MP@30fps
Use H.264 High Profile ,with high compression ratio
ICR switch automatically,realize real day/night surveillance
Support Web and Client dewarping by software
Be fit for outdoor big-area environment in different temperature and humidity
Support IP66 rated,IK10 impact resistance rate design
| Specifikáció |
| Camera Index 360 degree outdoor security camera | |
| DSP |
Hisilicon Series High Performance DSP |
| Sensor Type |
1/2.8″3.0 MP Pixel progressive scan CMOS |
| Number of Sensor |
8 |
| Electronic Shutter |
Manual/Auto;1/5s to 1/50,000s |
| Min Illumination |
Color：0.1Lux @ F1.2 AGC On B/W：0.001Lux@ F1.2 AGC On; |
| Objektív |
2.8mm fixed-focus |
| Viewing angle(H) |
360° |
| D/N |
Day / Night Mode |
| Noise Reduction Mode |
2D / 3D |
| Encoding Standard | |
| Video Compression |
H.264 |
| Coding standard |
H.264 Baseline/MainProfile/HighProfile Optional |
| Video compression rate |
800kbps~48Mbps |
| Image Index | |
| Max Image Size |
24.0MP / 8 x 2048×1536 (HDTV) |
| ePTZ |
Electronic Pan / Tilt / Zoom |
| Frame Rate | 8 x 2048×1536 @ 25fps (Pal) / 30fps (NTSC) ; |
| SN | ≥50dB |
| Image Setup | Auto white balance, Auto Gain, Auto Shutter |
| Network Function | |
| Intelligent Alarm |
Motion detection, tampering alarm, network disconnect, storage exception |
| Protecol |
IPv4/IPv6、RTSP/RTP/RTCP、TCP/UDP、HTTP、DHCP、DNS、FTP、DDNS、PPPoE、SMTP、Banjour |
| Interface Protocol |
V2.4.2 / CGI / SDK |
| General Function |
One-key recovery |
| Function Interface | |
| Network Port |
1 * RJ45 10M/100M/1000M Self-adaption Ethernet port |
| Serial interface |
RS485 |
| Alarm interface |
1 * input/output |
| General Specification | |
| Operating Conditions |
-40℃ ~ 60℃, humidty less than 95% (No condensation) |
| Power Supply |
DC12V±10%，3A |
| Power Consumption |
25W |
| Water-proof Level |
IP66 |
| Impact-resistant Level |
IK10 |
| Dimensions(mm) |
Φ228 x 330mm |
| Weight (kg) |
5.0 (net weight) |
| Application Scene |
The Panoramic 360 degree video security Camera can provide 360º vision,be fit for used to the surveillance situation which required to show wide area in single window,reducing installation difficulty of multiple normal camera.
This series of kültéri vízálló camera can be used large-scale square、traffic cross、industry park、shopping mall、stadium、exhibition & convention center so on,monitoring the activity of big area、tracking the stream of human and improving the management of region.
