Non-contact Body Measurement Warning Monitoring System Face Recognition AI Thermal Screening Imager IP 1080P 2MP Thermal Camera

State-of-the-art technologies have been utilized to develop and manufacture Non-contact Body Measurement Warning Monitoring System Face Recognition AI Thermal Screening Imager IP 1080P 2MP Thermal Camera.Having been tested multiple times,LSVISIONis able to give out its best effect in the field(s) of CCTV Camera.

Megosztás:

Shenzhen LSVISION Technology Co., Ltd. is a preferred manufacturer in the CCTV Camera industry. Innovation is at the core of the value that we deliver to our customers. The use of in Non-contact Body Measurement Warning Monitoring System Face Recognition AI Thermal Screening Imager IP 1080P 2MP Thermal Camera manufacturing has allowed us for more efficient use of resources and personnel.The product is highly recognized in the application field(s) of CCTV Camera. Since established, Shenzhen LSVISION Technology Co., Ltd. have always been in strict compliance with international standards and high ethical standards, thus offering customers highly reliable products. We have always been following the business principle of ‘honesty & integrity’, which ensures that the most credible services are delivered to every customer.

Származási hely: Guangdong, Kína Márkanév: LSVISION
Modellszám: LS-TI004 Garancia: 1 év
Különleges jellemzők: Temperature Measurement Érzékelő: CCD, 1/1.9″ CMOS
Stílus: BULLET CAMERA Funkció: Thermal image, Temperature detection
Videó tömörítési formátum: H.265 Adattárolási lehetőségek: NVR
Alkalmazás: Beltéri Testreszabott támogatás: Egyedi logó
A termék neve: Face Recognition AI Thermal Screening Imager IP 1080P Thermal Camera Képérzékelő: 1920x1080P
Target temperature: 35°C A 38°C ≤ 0.3 ℃ Gyújtótávolság: 2.7 ~ 12mm
Motion Detection: Támogatás Language: English, Chinese
Szín: Fehér Accuracy: ≤ 0.3 ℃
Tanúsítás: ce, FCC

Non-contact Body Measurement Warning Monitoring System Face Recognition AI Thermal Screening Imager IP 1080P 2MP Thermal Camera



Termék leírása
Fő jellemzők *On-board temp-detection algorithm * One IP address two channels * Effective pixels 400×300 * Sensitivity ≤40mK *Thermal: 8mm Fixed lens, Visible: 2.7~12mm motorized lens * Accuracy ±0.3°C * Body temperature measurement up to 30 Targets *Response Time ≤30ms *17 color control
Modell
LS-TI004
Hőkamera

Detector Type
Uncooled IRFPA Microbolometer
Hatékony pixelek
400(H) ×300(V)
Pixel Size
17um
Thermal Sensitivity (NETD)
≤40mK @F1.0, 300K
Spectral Range
 8~14um
Kép beállítása
Polarity LUT/ DVE/ Mirror/ FCC/ /3D DNR Brightness/Contrast/ ROI
Thermal Lens

Objektív típusa
Fixed
Focus Control
Manual Focus
Focal Length
8mm
F No.
84° x 45° (H x V)
Focal Length
F1.0
Angle of View
H: 46°, V: 35°
Visible Camera

Képérzékelő
1/2.8″ CMOS
Effective Resolution
1920(H)×1080(V)
Shutter Speed
1/5 ~ 1/20,000s
Interface

Ethernet
1 Ethernet (10/100 Base-T) RJ-45 Connector
Audio Interface
1ch Audio In,1ch Audio Out
Riasztás
2ch Alarm In,2ch Alarm Out
RS485
Támogatás
Általános

Tápegység
DC12V/POE (IEEE 802.3af)
Energiafogyasztás
Max 10W
Operating Temperature
-30°C~60°C(-22°F~140°F)
Storage Conditions
0~ 90% RH
Ingress Protection
IP66
Casing
Fém
